XLPE/Copper Wire Shield/PVC, 15 kV, UL Type MV-105, 133% Ins. Level, 220 Mils,Medium-Voltage Power Cable

Place of Origin:Hebei, China (Mainland)              Brand Name:Prisaman
Model Number:URD cable,MV-90,MV-105          Insulation Material:XLPE
Type:Medium Voltage                                            Application:Industrial
Conductor Material:Copper or aluminum            Jacket:LLDPE,PVC,XLPE
Certificate:UL                                                    Standard:UL1072,IECA94-946
Conductor:Copper or Aluminum                     Core:Single or Three Cable
Insulation:EPR or XLPE                                     Insulation Level:100% or 133%
Shield Type:Copper wire or Copper Tape    Rated voltage:5KV,15KV,25KV,35KV
Jacket Color:Black with Red strip               Working Temperature:105°C Rating

XLPE/Copper Wire Shield/PVC, 15 kV, UL Type MV-105, 133% Ins. Level, 220 Mils,Medium-Voltage Power Cable

APPLICATIONS

URD  TRXLPE insulated cables are designed and manufactured to meet the applications of primary underground distribution suitable for use in wet or dry location, direct burial, underground duct, and exposed to sunlight, To be used at 5kV upto 35kV at conductor temperatures not to exceed 90 deg. C for normal operation.

SPECIFICATIONS

TRXLPE insulated URD cables meets or exceeds all applicable requirements of thefollowing standards, and guaranteed all cables manufactured and tested under this standards.

– ANSII ICEA S94-649

– AEIC CS-8

– ASTM B-3, ASTM B-8, ASTM B-230 & ASTM B-231

– UL1072

CONSTRUCTION

Conductor : Bare aluminium or copper, stranded class B compressed stranding

Conductor Shield :Extruded semi-conducting compound

Insulation : TRXLP (TreeRetardant XLPE) or XLPE

Insulation Shield : Extruded semi-conducting compound

Concentric Neutral : Uncoated copper concentric neutral wires (coated copper are optional)

Encapsulated Jacket : Non-conducting LLDPE embedded jacket with extruded red stripes.

PVC or Semi-conducting jacket are available upon request

MAXIMUM CONDUCTOR TEMPERATURE

Normal continuous at 90 ℃, Overload at 130  ℃ and Short circuit at 250   ℃

FEATURES & BENEFITS, OPTIONS

– Triple extruded construction by dry curing process guarantees excellent quality of cables

– TRXLPE insulation offers proven superior life span than conventional XLPE cables

– Triplex type is optional, it brings you saving installation cost

– Strand-filled conductor & Water-blocking jacket is available upon request

DATE SHEET

 Condctor  Copper Neutral  (1/3) diameter(inch) Weight (Pounds)
 AWG orMCM  Stranding  Number of Wires  SizeAWG (Solid)  Conductor  Over

Insulation

 Over Insul.

Shield

 Over Neutral

Wires

Over

Encaps. Jkt.

Conductor Concentric

Neutral

 TotalNo

Jacket

 Total WithJacket
 1/0  19 wire  9  14  0.37  1.12  1.23  1.35  1.46  325.8  119.2  659  4926
 2/0  19 wire  11  14  0.42  1.17  1.27  1.40  1.50  410.9  146.3  775  808
 3/0  19 wire  14  14  0.47  1.22  1.32  1.48  1.59  518.1  185.9  900  923
 4/0  19 wire  11  12  0.53  1.28  1.38  1.54  1.71  653.3  228.0  1110  1055
 250  37 wire  13  12  0.57  1.33  1.44  1.64  1.81  771.9  282.1  1330  1292
 350  37 wire  12  10  0.68  1.44  1.54  1.70  1.89  1081  398.0  1633  1519
 500  37 wire  17  10  0.81  1.57  1.72  1.88  2.04  1544  543.5  2002  1886
 750  61 wire  25  10  0.99  1.76  1.93  2.11  2.28  2316  801.5  2650  2289
 1000  61 wire  33  10  1.14  1.92  2.06  2.27  2.43  3088  1058  3847  2960
